CLEARANCE (DARK GREY-Hammertone) Left Side Rising Tilting Swing Gate Hinge System High Rise Version
$100.00
$50.00
Save $50.00
- Freight from $25.00 Calculate Freight
- 1 Year Warranty
- Brand : Alpha Automation
In stock
Rising Gate Hinge System-High Rise Version
The rising hinge system allows for a tilted opening angle beginning from when the gate begins its opening till it reaches the full open position, this allows the special hinge system to open when a driveway has a grade uphill.
Typically the hinge separation will determine the final rise amount, the close the top and bottom hinges are to one another the greater the rise, the further away from one another the less the rise amount. Please see the chart below on some typical examples.
✓ Steel Hinges
✓ Ball Joint in Each Hinge
✓ DARK GREY Colour
✓ Bottom support plate included for weightier gates
✓ Maximum 150KG capacity
Rising Gate Guideline (HIGH RISE VERSION)
| Gate Width (mm) | Gate Rise (mm) | Hinge Separation (mm) |
| 900 | 275 | 750 |
| 900 | 235 | 900 |
| 900 | 160 | 1360 |
| 900 | 140 | 1650 |
| 900 | 200 | 1060 |
| 900 | 180 | 1200 |
| 900 | 140 | 1400 |
| 900 | 150 | 1460 |
| 900 | 130 | 1760 |
| 900 | 125 | 1900 |
| 1200 | 240 | 1060 |
| 1200 | 220 | 1200 |
| 1200 | 195 | 1360 |
| 1200 | 170 | 1400 |
| 1200 | 180 | 1460 |
| 1200 | 165 | 1650 |
| 1200 | 150 | 1760 |
| 1200 | 145 | 1900 |
| 1500 | 290 | 1060 |
| 1500 | 255 | 1200 |
| 1500 | 230 | 1360 |
| 1500 | 200 | 1400 |
| 1500 | 210 | 1460 |
| 1500 | 190 | 1650 |
| 1500 | 180 | 1760 |
| 1500 | 175 | 1900 |
| 1800 | 460 | 750 |
| 1800 | 390 | 900 |
| 1800 | 330 | 1060 |
| 1800 | 290 | 1200 |
| 1800 | 260 | 1360 |
| 1800 | 235 | 1400 |
| 1800 | 240 | 1460 |
| 1800 | 220 | 1650 |
| 1800 | 210 | 1760 |
| 1800 | 200 | 1900 |
| 2100 | 380 | 1060 |
| 2100 | 385 | 1200 |
| 2100 | 300 | 1360 |
| 2100 | 270 | 1400 |
| 2100 | 270 | 1460 |
| 2100 | 250 | 1650 |
| 2100 | 235 | 1760 |
| 2100 | 225 | 1900 |
