Heavy Duty Sliding Gate Opener 400KG Access Secure Kit with Limit Switches and Encoder Made in Italy

Name: Heavy Duty Sliding Gate Opener 400KG Access Secure Kit with Limit Switches and Encoder Made in Italy
SKU: BXV400-P-AS
Price: 1165 AUD
Availability: InStock

SKU: BXV400-P-AS

$1,201.00

$1,165.00

Save $36.00

Freight from $30.00 Calculate Freight
2 Year Warranty
Brand : CAME x ASA

2 Year Warranty

14 Metre Gate

400KG Max.

Made In Italy

240V to 24V System

BXV

Adjustable Limit Switch

2 Year Warranty
14 Metre Gate
400KG Max.
Made In Italy
240V to 24V System
BXV
Adjustable Limit Switch

In stock

Click & Collect

Delivery

In-Store

Special Order- 48HR Dispatch*

Heavy Duty Sliding Gate Motor with Encoder and Limit Switches

24v low voltage sliding gate motor power at gate installation

The BXV 400 is designed to suit a variety of different applications from typical sliding gates in a domestic home up to extra long 14m length gates in a commercial environment, all this with a 400KG weight capacity. A 600KG version is also available (with the option for ultra fast).

With top of the line features like 3 stage speed control, precise encoder travel and the reliable spring limit system longevity is the basis of design.

All-in-One and Feature Packed

For ease of configuration the cutting edge digital control board is housed at the top of the unit allowing for easy changes to any one of the numerous features of the system.

Further key benefits of the BXV system is the motor is controlled by an encoder giving precise and accurate operation along with its slowdowns, all completely adjustable including the speed and slow points.

The stopping point at each end is controlled by an easy to setup and durable spring limit system not affected by the Australian climate (unlike magnetic limits).

ultra fast 24v sliding driveway roller gate motor best quality low voltage system

Four point adjustment

bxv sliding motor adjustable levelling system for sliding gates on out of level incline installations

As is often the case concreting is never perfect and is more apparent once a motor is installed, this is remedied by the FOUR point adjustment system of the BXV.

Simply adjust each corner of the motor chassis up/down to return the unit to level in both directions. This will allow for easy gear rack installation to the gate since alignment is set to suit

Manual Release

Easy to use manual release incase of power outage. Insert the supplied key and turn to unlock the manual release lever. To release turn the manual release lever and now the gate can be opened and closed manually. If required a battery backup system is available for completely uninterrupted operation. The system is completely housed within the unit.

Specifications

maximum size and weight of residential sliding gate system

Maximum Gate Width	14M
Maximum Gate Weight	400KG Each
Speed (M/Min)	12M/Min
Encoder	Yes
Motor Power (Volts)	24V DC
Power (Watts)	170W
IP Rating	44
Operating Temperature	-20° to +55° C
Thrust (Nm)	350N
Duty Cycle	80%

Digital Control Board

By default the control board will be pre-configured for the best typical settings for most users however with the onboard digital display and easy to use scroll buttons the configuration options are almost endless. Out of the box it will be configured for Both Full Gate OPEN/CLOSE + Partial Opening Function (a set amount of the gates travel) in a home you would just enable and set the automatic close timer (if required) and that’s it. However in an installation with a longer driveway you may want to adjust the pedestrian command to be an OPEN ONLY input allowing for the use of a loop detector to be used to detect vehicles approaching the gate and open automatically (and optionally close on the automatic close timer if enabled)

Power Inputs and Outputs

Typical input and outputs to power the system and any wired in accessories

24V Power Input

24V Power Output For Accessories

Configurable Methods Of Operation

Wireless and Wired equipment can be configured in a number of different ways to support the best suited operation for the site, by default the system is configured for typical usage being full gate operation and partial opening

Full Gate Operation

Partial (Opens the gate partially for pedestrian access)

Open Only

Close Only

Motor Specifics

Default configurations are already set however, if required further adjustment can be made to suit all installations

ENCODER Control

Automatic Calibration (with Adjustable Calibration Speed)

Motor Test (used for checking your directions prior to calibration)

Adjustable Thrust

Adjustable Travel Speed

Adjustable Sensitivity

Adjustable Slowdown Speed

Adjustable Slowdown Position

Light Control

Multiple options for visible safety alerts, illuminating the driveway OR Both

Flashing/Static Illuminated Light from OPEN til CLOSED

Additional Output for Flashing During Opening

bxv 24v driveway and entrance sliding gate motor control board with digital display advanced features high quality italian made

Safety Devices

Plenty of support to protect occupants, visitors and there vehicles

Supports Photocell Sensors

Supports Reflective Sensors

Supports Safety Edge

Supports Induction Loops for Safety

Supports STOP Button

Supports Maintained Action (Hold to OPEN/CLOSE)

Operational Control

Infinite support for accessories and methods of operation

Remote Control

Wireless Keypads

Wired Keypads

Wired Button

Induction Loops

Intercom Systems

STX4K Keyring High Range Remote

Automation systems Australia keyring remote control for driveway gate

The STX4K Keyring remote is a class leader in long range (up to 100 metres open air) and high security remote transmitters, using Keeloq rolling code technology provides the ultimate layer of security for your remote against over the air radio code thefts and copies of your remote which in-turn stops unwanted access or intrusions to your property.

The Four buttons allow for usage of multiple features available from the gate system controller as well as the use on other gates and garage doors through the use of an external receiver (available separately).

Key Features

✓ Up to 100 metres distance in open air
✓ Keeloq rolling code security
✓ Easy to Use yet SLIGHTLY set in buttons to prevent accidental operation
✓ Clear visibility red LED indicator which will illuminate upon a button press
✓ Hard plastic buttons to prevent stuck in buttons and splits from finger nails
✓ Slimline and modern ergonomic design
✓ Can work with garage doors, other brand gates, alarms etc. through the use of a remote receiver module

Dukie X 32KHZ Anti-Interference Professional Photocell Kit

Dukie X Automatic gate and garage door photocell

The Dukie X series photocell kit will provide an invisible to the eye infrared beam across the driveway to prevent the gate closing from obstacles in the beams path. Both the photocells are wired back to the control box with low voltage.

Added benefits of the X series photocell is its Anti Interference Infrared frequency (32KHZ) making it best suited for ultra high capacity electric motors.

Key Features

✓ Ultra modern and neat appearance
✓ Compact design fits almost anywhere at 81(L)x65(W)x29(D)mm
✓ NO and NC Relay Settings
✓ Excellent range characteristics of up to 10 meter distance between each photocell
✓ Multiple sets can be installed on each system for added protective layers (with Synchronization setting)

Dex 4 Wireless Keypad

The Dex 4 Wireless Keypad can communicate directly to the gate system using the same Keeloq secure rolling code signal as the remotes allowing for an easy installation process without the need for wiring.

Due to its high quality chipset the open air signal strength can exceed an astounding 80 meters. This makes the Dex 4 not only suited to controlling the gate but could actually be used to control the garage door, another gate etc. providing they have the compatible receiver installed, Up to FOUR devices/features could be used with individual pin codes for each due to its four independent output channel designs.

Key Features

✓ Three colour options are available: Classic White, Subtle Grey and Deep black
✓ Compact design fits almost anywhere at 90(L)x77(W)x35(D)mm
✓ Control Up to four systems or four features on different pin codes
✓ Astounding open air distance of 80 metres
✓ Works on 2x AAA batteries (supplied)
✓ Audible and LED indicators
✓ Totally wireless (wire free) easy installation

Kit Contents (See Description Tab for Full In-Depth Details)

Description

Please note this is a replacement operator and is not supplied with gear rack, remotes or receiver card.

Heavy Duty Sliding Gate Motor with Encoder and Limit Switches

The BXV 400 is designed to suit a variety of different applications from typical sliding gates in a domestic home up to extra long 14m length gates in a commercial environment, all this with a 400KG weight capacity. A 600KG version is also available (with the option for ultra fast).
With top of the line features like 3 stage speed control, precise encoder travel and the reliable spring limit system longevity is the basis of design.

All-in-One and Feature Packed

For ease of configuration the cutting edge digital control board is housed at the top of the unit allowing for easy changes to any one of the numerous features of the system.

Further key benefits of the BXV system is the motor is controlled by an encoder giving precise and accurate operation along with its slowdowns, all completely adjustable including the speed and slow points.

The stopping point at each end is controlled by an easy to setup and durable spring limit system not affected by the Australian climate (unlike magnetic limits).

Four point adjustment

As is often the case concreting is never perfect and is more apparent once a motor is installed, this is remedied by the FOUR point adjustment system of the BXV.
Simply adjust each corner of the motor chassis up/down to return the unit to level in both directions. This will allow for easy gear rack installation to the gate since alignment is set to suit

Manual Release

Easy to use manual release incase of power outage. Insert the supplied key and turn to unlock the manual release lever. To release turn the manual release lever and now the gate can be opened and closed manually. If required a battery backup system is available for completely uninterrupted operation. The system is completely housed within the unit.

Specifications

Maximum Gate Width 14M
Maximum Gate Weight 400KG Each
Speed (M/Min) 12M/Min
Encoder Yes
Motor Power (Volts) 24V DC
Power (Watts) 170W
IP Rating 44
Operating Temperature -20° to +55° C
Thrust (Nm) 350N
Duty Cycle 80%

Digital Control Board

By default the control board will be pre-configured for the best typical settings for most users however with the onboard digital display and easy to use scroll buttons the configuration options are almost endless. Out of the box it will be configured for Both Full Gate OPEN/CLOSE + Partial Opening Function (a set amount of the gates travel) in a home you would just enable and set the automatic close timer (if required) and that’s it. However in an installation with a longer driveway you may want to adjust the pedestrian command to be an OPEN ONLY input allowing for the use of a loop detector to be used to detect vehicles approaching the gate and open automatically (and optionally close on the automatic close timer if enabled)

Power Inputs and Outputs

Typical input and outputs to power the system and any wired in accessories
24V Power Input
24V Power Output For Accessories

Configurable Methods Of Operation

Wireless and Wired equipment can be configured in a number of different ways to support the best suited operation for the site, by default the system is configured for typical usage being full gate operation and partial opening
Full Gate Operation
Partial (Opens the gate partially for pedestrian access)
Open Only
Close Only

Motor Specifics

Default configurations are already set however, if required further adjustment can be made to suit all installations
ENCODER Control
Automatic Calibration (with Adjustable Calibration Speed)
Motor Test (used for checking your directions prior to calibration)
Adjustable Thrust
Adjustable Travel Speed
Adjustable Sensitivity
Adjustable Slowdown Speed
Adjustable Slowdown Position

Light Control

Multiple options for visible safety alerts, illuminating the driveway OR Both
Flashing/Static Illuminated Light from OPEN til CLOSED
Additional Output for Flashing During Opening

Safety Devices

Plenty of support to protect occupants, visitors and there vehicles
Supports Photocell Sensors
Supports Reflective Sensors
Supports Safety Edge
Supports Induction Loops for Safety
Supports STOP Button
Supports Maintained Action (Hold to OPEN/CLOSE)

Operational Control

Infinite support for accessories and methods of operation
Remote Control
Wireless Keypads
Wired Keypads
Wired Button
Induction Loops
Intercom Systems

x

400 KG Heavy Duty Sliding Gate Motor (Internal Transformer)
- 400KG /14 Mtr Capacity
- Internal Stepdown Transformer
- Prewired with Power Cord (1.2m)
- 3 Stage Speed
- Encoder Control
Show more
400KG /14 Mtr Capacity

Internal Stepdown Transformer

Prewired with Power Cord (1.2m)

3 Stage Speed

Encoder Control
×
Out Of Stock

QUIET 520mm (Clip In Key - Keyway) Sliding Gate Gear Rack Nylon Coated over Steel Reinforced

Out Of Stock

Gear Rack *

Clear

Out Of Stock

Description

Please be aware this product is only compatible with Automation Systems Australia Control Boards and Remote Receivers, it will NOT work with other brand products.

STX4K Keyring High Range Remote

The STX4K Keyring remote is a class leader in long range (up to 100 metres open air) and high security remote transmitters, using Keeloq rolling code technology provides the ultimate layer of security for your remote against over the air radio code thefts and copies of your remote which in-turn stops unwanted access or intrusions to your property.

The Four buttons allow for usage of multiple features available from the gate system controller as well as the use on other gates and garage doors through the use of an external receiver (available separately).

Key Features

✓ Up to 100 metres distance in open air
✓ Keeloq rolling code security
✓ Easy to Use yet SLIGHTLY set in buttons to prevent accidental operation
✓ Clear visibility red LED indicator which will illuminate upon a button press
✓ Hard plastic buttons to prevent stuck in buttons and splits from finger nails
✓ Slimline and modern ergonomic design
✓ Can work with garage doors, other brand gates, alarms etc. through the use of a remote receiver module

x

Four Button Keyring Remote Control (White)
- Up to 100 Metre Open Air Distance
- High Security Rolling Code
- Slimline and Ergonomic
Show more
Up to 100 Metre Open Air Distance

High Security Rolling Code

Slimline and Ergonomic
×
Out Of Stock

Provide a Sun Visor Clip? ($3) *
Clear
Out Of Stock

Automatic Gate Remote Control Keyring Mounting STX4K White quantity
Description

Please be aware this product is only compatible with Automation Systems Australia Control Boards and Remote Receivers, it will NOT work with other brand products.

STX4K Keyring High Range Remote

The STX4K Keyring remote is a class leader in long range (up to 100 metres open air) and high security remote transmitters, using Keeloq rolling code technology provides the ultimate layer of security for your remote against over the air radio code thefts and copies of your remote which in-turn stops unwanted access or intrusions to your property.

The Four buttons allow for usage of multiple features available from the gate system controller as well as the use on other gates and garage doors through the use of an external receiver (available separately).

Key Features

✓ Up to 100 metres distance in open air
✓ Keeloq rolling code security
✓ Easy to Use yet SLIGHTLY set in buttons to prevent accidental operation
✓ Clear visibility red LED indicator which will illuminate upon a button press
✓ Hard plastic buttons to prevent stuck in buttons and splits from finger nails
✓ Slimline and modern ergonomic design
✓ Can work with garage doors, other brand gates, alarms etc. through the use of a remote receiver module

x

Four Button Keyring Remote Control (Black)
- Up to 100 Metre Open Air Distance
- High Security Rolling Code
- Slimline and Ergonomic
Show more
Up to 100 Metre Open Air Distance

High Security Rolling Code

Slimline and Ergonomic
×
Out Of Stock

Provide a Sun Visor Clip? ($3) *
Clear
Out Of Stock

Automatic Gate Remote Control Keyring Mounting STX4K Black quantity

Dukie X OR Dukie XR Photocells

Choose from Photocell wired to both sides OR a Reflective sensor Wired only on the one side (1.9m Pre-Connected)

Out Of Stock

X Series Photocell Kit *

Clear

Out Of Stock

Description

Please be aware this product is only compatible with Automation Systems Australia Control Boards and Remote Receivers, it will NOT work with other brand products.

Dex 4 Wireless Keypad

The Dex 4 Wireless Keypad can communicate directly to the gate system using the same Keeloq secure rolling code signal as the remotes allowing for an easy installation process without the need for wiring.

Due to its high quality chipset the open air signal strength can exceed an astounding 80 meters. This makes the Dex 4 not only suited to controlling the gate but could actually be used to control the garage door, another gate etc. providing they have the compatible receiver installed, Up to FOUR devices/features could be used with individual pin codes for each due to its four independent output channel designs.

Key Features

✓ Three colour options are available: Classic White, Subtle Grey and Deep black
✓ Compact design fits almost anywhere at 90(L)x77(W)x35(D)mm
✓ Control Up to four systems or four features on different pin codes
✓ Astounding open air distance of 80 metres
✓ Works on 2x AAA batteries (supplied)
✓ Audible and LED indicators
✓ Totally wireless (wire free) easy installation

Power 2xAAA Batteries (Supplied)

Operating Distance 80 Meters Open Air

Frequency Secure Rolling Code 433MHZ

Operating Channels 4

Transmitting Time 1.5s

x

Wireless Keypad (Three colour options)

Four channel wireless keypad allowing for full control of all automatic gate features without the need for wiring.

Show more

Four channel wireless keypad allowing for full control of all automatic gate features without the need for wiring.

×

Out Of Stock

Colour *
Clear
Out Of Stock

Wireless Pin Code/Password Keypad for Automatic Gates and Garage Doors 433MHZ quantity

Optional Add On's

Description
Particularly handy for those unexpected power outages or storms. This system is a must to keep your gates operational when the powers out.

System operation will remain uninterrupted including any wired or wireless accessories.

Charging of the batteries will automatically take place once the power to the system is restored.

Also a great solution when its not possible to reach the manual release system be it due to the design of the gate or no other access into the property.

Compatibility:

FTX System (Fits Internally)
BXV Systems (Fits Internally)
ZLX24 Control Box (Requires additional SMALL Enclosure)
ZL65 Control Box (Requires additional SMALL Enclosure)
x
Uninterrupted Battery Backup System
Direct connection into the system allowing for uninterrupted use.

Show more

Direct connection into the system allowing for uninterrupted use.

×
Add for

$229.00

$177.00

Save $52.00

Out Of Stock
Description

Please be aware this product is only compatible with Automation Systems Australia Control Boards and Remote Receivers, it will NOT work with other brand products.

STX4L Ultra Long Distance Remote

The STX4L Long distance remote is a class leader in Ultra long distance (up to 800 metres open air) and high security remote transmitters, using Keeloq rolling code technology provides the ultimate layer of security for your remote against over the air radio code thefts and copies of your remote which in-turn stops unwanted access or intrusions to your property.

The Four buttons allow for usage of multiple features available from the gate system controller as well as the use on other gates and garage doors through the use of an external receiver (available separately).

The long distance remote is most useful around larger properties able to operate the gate from sheds, buildings and the home where a typical remote would not be able to achieve the same operating distance.

Key Features

✓ Up to 800 metres distance in open air
✓ Keeloq rolling code security
✓ Easy to Use buttons
✓ ON/OFF switch to prevent accidental operation
✓ Clear visibility LED indicator which will illuminate upon a button press
✓ Narrow handheld design
✓ Can work with garage doors, other brand gates, alarms etc. through the use of a remote receiver module

x

Automatic Gate Long Distance Remote Control (Long Range Remote)
- Up to 800 Metre Open Air Distance
- High Security Rolling Code
- Side Switch Prevents Accidental Operations
Show more
Up to 800 Metre Open Air Distance

High Security Rolling Code

Side Switch Prevents Accidental Operations
×
Add for

$45.00

Out Of Stock
Description

Dual Channel Remote Control Receiver

Working with the STX4K, STX4L and Dex4 Wireless equipment the Two Channel receiver offers the ability to control up to two individual devices/systems separately such as automatic gate systems, garage doors, alarm systems and almost any device with the requiring a momentary pulse OR latching circuit to operate.

Specifications

Operating Voltage 12-30VDC/12-24VAC

Operating Current 9mA standby

Relay Switching Current Capacity 3A Momentary/500mA Latching

Frequency 433mhz

Compatible Transmitters (tX) STX4L, STX4K, Dex4

x

Receiver for Garage Doors

Operate your garage door from a different button on the remote using this expander module.

Show more

Operate your garage door from a different button on the remote using this expander module.

×
Add for

$40.00

Out Of Stock
Description

Push/Press Button

The push button is the simplest of all access control devices, a simple press of the button allows the automation to begin its working. Generally installed on the inside of the property within close proximity to the user (driver side when exiting) allows for the easiest method of working.

Key Features

✓ Weatherproof for outdoor use and can be used indoors ✓ Supports NO and NC circuits (when used as a wired button) ✓ 2 Wire connection or Wireless Option (Automation Systems Australia ONLY) ✓ Easy to operate

x

Weatherproof Press Button

Typical press button for foot traffic, suitable for outdoor and indoor installations.

Show more

Typical press button for foot traffic, suitable for outdoor and indoor installations.

×
Add for
$35.00 – $70.00

Out Of Stock

Wired or Wireless *
Clear
Out Of Stock
Description

Big Head (Mushroom) Push/Press Button

The push button is the simplest of all access control devices, a simple press of the button allows the automation to begin its working. Generally installed on the inside of the property within close proximity to the user (driver side when exiting) allows for the easiest method of working.

Key Features

✓ Weatherproof for outdoor use and can be used indoors ✓ Supports NO and NC circuits (when used as a wired button) ✓ 2 Wire connection or Wireless Option (Automation Systems Australia ONLY) ✓ Easy to operate

x

Weatherproof Push Button (Mushroom Head)

Typical press button for vehicles mounted to a bollard, suitable for outdoor and indoor installations.

Show more

Typical press button for vehicles mounted to a bollard, suitable for outdoor and indoor installations.

×
Add for
$35.00 – $70.00

Out Of Stock

Wired or Wireless *
Clear
Out Of Stock
Description

Weekly Schedule Automatic Gate Timer

The weekly timer allows for scheduling open time cycles to operate the gate, simple set the open time and once lapsed the gate would automatically close (automatic close timer must be enabled).

The timer allows for independent 5 day business week, INDEPENDENT days configurations OR a full 7 day week configuration along with other modes. Up to 8 different On/Off schedules can be set.

Key Features

✓ Automatic Opening and Closing at the Set times
✓ LCD Display
✓ Built in Battery to retain schedules, replaced every 2-3 years
✓ Simple setting by: independent days schedule, Common time 5 day working week (MON-FRI), Weekends Combined (SAT+SUN) or Common time 7 day week (MON-SUN)

Specifications

Operating Voltage 12V DC

Power Consumption 50mA

Display LCD

Load Capacity 10A/250V

Programs 8

Relay NO/NC

x

Weekly Auto Open/Close Scheduled Timer

Programable timer with numerous configurations options on when to open and close the gate.

Show more

Programable timer with numerous configurations options on when to open and close the gate.

×
Add for

$69.00

Out Of Stock
Description

WIRELESS Automatic Vehicle Detection Sensor – for Automatic Opening of gate

An easy to install WIRELESS AUTOMATIC OPENING driveway vehicle detection system

Multiple hours saved, materials saved and frustrations gone

Long gone are the days of cutting concrete, chasing wires and configuring induction loop detectors (ground loop). Finally, a simple WIRELESS solution to streamline the installation process.
The WIRELESS loop detector SIMPLY BOLT DOWN to a concrete driveway (or concrete pad in gravel driveways) and wirelessly communicate back with the gate system using the supplied high security (128 Bit) transceiver for two way communication between the New Generation wireless loops.

The wireless exit “loop” is maintenance free and installed with 2x AA Lithium batteries for a THREE YEAR use period before a battery replacement is required (regular usage), to replace the batteries simply remove the top cover and fit the new Lithium AA batteries.

How does it work and what happens if I accidently drive over it?
The wireless loop is designed for a vehicle to drive over and will detect the undercarriage of the vehicle, if its accidently driven over it presents no issue whatsoever as its casing carries a static load capacity of 2500kg.

How far can i have it from the gate?
Thanks to its high transmission range capabilities it has a maximum wireless operating distance of 50 meters.

How big is it?
Its compact form factor allows for a discreet installation measuring only 120x120mm Length and Width and only 30mm in height.

Will it work with my system?
Typically, YES, it will work with any gate system that has an open command input and an accessories voltage output of 12-24V DC

Which installations does this suit?
Any domestic installations which fit the following criteria:
✓A concrete pad or driveway is available for the device to be installed on to
✓When a vehicle is parked it does not sit within 3 meters of the device
✓The device does not sit in a recess and pool water, snow or any debris
✓Not nearby to high voltage cables

How is it installed?
1. Connect the transceiver to the gates control board, this must be installed within the gate controller or any enclosure
2. Power on the transceiver and have the loop touching the antenna of the transceiver.
3. Once the transceiver flashes its blue led and the loop flashes its yellow led they are now paired together.
4. Remove backing plate from the loop and install to concrete using the supplied concrete screw bolts, ensure the arrow faces the direction of travel for exit (faces towards the gate).
5. Install the wireless loop to the backing plate and allow 3 minutes for calibration
Test to confirm operation, job done!

Supplied With

✓1x Wireless Loop (with 2x AA Lithium Batteries Installed)
✓1x Transceiver
✓2x Concrete Screw Bolts

Detection Area

Replaceable Battery Life

x

Automatic Opening WIRELESS Automatic Vehicle Detection Sensor

This WIRELESS system can automatically open the gate as your vehicle passes over it. Installed up to 50 metres away from the gate!

Show more

This WIRELESS system can automatically open the gate as your vehicle passes over it. Installed up to 50 metres away from the gate!

×
Add for

$460.00

Out Of Stock

Access Control Keypad with EM Tag Reader and mobile APP

Wired keypad allowing for pin code access control, em cards and tags operation, along with mobile APP control.

Add for

$150.00 – $190.00

Out Of Stock

Mobile App Control Wi-Fi Connection Module

Control the gate from anywhere in the world with your mobile phone using the Tekno WF module.

Add for

$79.00

Out Of Stock

Manuals

Heavy Duty Sliding Gate Opener 400KG Access Secure Kit with Limit Switches and Encoder Made in Italy

$1,201.00

$1,165.00

Save $36.00

In stock

Power	12V DC
Standby Current	≤35mA
Maximum Users	10,000 Users
Operating Temperature	-40°C - +60°C
Operating Methods	PIN CODE, RFID,MOBILE APP
Wi-Fi Distance	Up to 10m on basic ISP routers (entry level basic) Substantially boosted on a good quality router or mesh network

Operating Voltage	5-24V DC
Consumption	≤35mA Standby/≤100mA Operation
Smart Assistant Support	YES
Operating Methods	Mobile APP
Wi-Fi Distance	Up to 10m on basic ISP routers (entry level basic) Substantially boosted on a good quality router or mesh network

Power	2xAAA Batteries (Supplied)
Operating Distance	80 Meters Open Air
Frequency	Secure Rolling Code 433MHZ
Operating Channels	4
Transmitting Time	1.5s

Operating Voltage	12-30VDC/12-24VAC
Operating Current	9mA standby
Relay Switching Current Capacity	3A Momentary/500mA Latching
Frequency	433mhz
Compatible Transmitters (tX)	STX4L, STX4K, Dex4

Operating Voltage	12V DC
Power Consumption	50mA
Display	LCD
Load Capacity	10A/250V
Programs	8
Relay	NO/NC

Heavy Duty Sliding Gate Opener 400KG Access Secure Kit with Limit Switches and Encoder Made in Italy

Heavy Duty Sliding Gate Motor with Encoder and Limit Switches

All-in-One and Feature Packed

Four point adjustment

Manual Release

Specifications

Digital Control Board

Power Inputs and Outputs

Configurable Methods Of Operation

Motor Specifics

Light Control

Safety Devices

Operational Control

STX4K Keyring High Range Remote

Key Features

Dukie X 32KHZ Anti-Interference Professional Photocell Kit

Key Features

Dex 4 Wireless Keypad

Key Features

Kit Contents (See Description Tab for Full In-Depth Details)

Description

Please note this is a replacement operator and is not supplied with gear rack, remotes or receiver card.

Heavy Duty Sliding Gate Motor with Encoder and Limit Switches

All-in-One and Feature Packed

Four point adjustment

Manual Release

Specifications

Digital Control Board

Power Inputs and Outputs

Configurable Methods Of Operation

Motor Specifics

Light Control

Safety Devices

Operational Control

400 KG Heavy Duty Sliding Gate Motor (Internal Transformer)

Description

Extra Heavy Duty Sliding Gate Gear Rack

QUIET 520mm (Clip In Key - Keyway) Sliding Gate Gear Rack Nylon Coated over Steel Reinforced

Description

STX4K Keyring High Range Remote

Key Features

Four Button Keyring Remote Control (White)

Description

STX4K Keyring High Range Remote

Key Features

Four Button Keyring Remote Control (Black)

Description

Dukie XR Retro-Reflective Sensor

Key Features

Dukie X OR Dukie XR Photocells

Description

Dex 4 Wireless Keypad

Key Features

Wireless Keypad (Three colour options)

Optional Add On's

Description

Uninterrupted Battery Backup System

Description

STX4L Ultra Long Distance Remote

Key Features

Automatic Gate Long Distance Remote Control (Long Range Remote)

Description

Dual Channel Remote Control Receiver

Specifications

Receiver for Garage Doors

Description

Push/Press Button

Key Features

Weatherproof Press Button

Description

Big Head (Mushroom) Push/Press Button

Key Features

Weatherproof Push Button (Mushroom Head)

Description

Weekly Schedule Automatic Gate Timer

Key Features

Specifications

Weekly Auto Open/Close Scheduled Timer

Description

WIRELESS Automatic Vehicle Detection Sensor – for Automatic Opening of gate
